Quick Interchangeable Crimping Series

View pictures

Modular crimping system that easily adapts to different applications through quick die-set changes, eliminating the need for additional tools.

Create the right crimping solution with our:

  • Pre-configured kits with an 8.7" or 10" crimping tool in carbon steel or aluminium, supplied with application-specific die sets:
    • Die-set assortment: ASSAETOOL02-1
    • Carbon steel kits: ASSAETOOL02, ASSAETOOL03, ASSAETOOL04, ASSAETOOL10, ASSAETOOL55, ASSAETOOL60, ASSAETOOL61, ASSAETOOL62
    • Aluminium kit: ASSAETOOL33
  • Custom configurations: combine compatible crimping tools and die sets to suit your specific application.
    • ASSAETOOL CASE and 9086BB are empty carrying cases with space for one 8.7" crimping tool and two to five die sets.
Prt nr. Product image Description Datasheet
MHQIBE  8,7" carbon steel ratchet tool
No die set included		 view
HJ43I 8,7" aluminum ratchet tool
No die set included		 view
HJ56I 10" carbon steel ratchet tool
No die set included		 view
DSQIA  For insulated terminals
AWG 22-18 / 16-14 / 12-10
0.5-1.0 / 1.5-2.5 / 4.0-6.0 mm²		 view
DSQIA1 For heat shrink butt connectors
AWG 22-18 / 16-14 / 12-10
0.5-1.0 / 1.5-2.5 / 4.0-6.0 mm²		 view
DSQIA2 For fully insulated female disconnectors
AWG 22-18 / 16-14 / 12-10
0.5-1.0 / 1.5-2.5 / 4.0-6.0 mm²		 view
DSQIA3 For miniature insulated terminals
AWG 26-22 / 24-18 / 22-16
0.1-0.5 / 0.25-1.0 / 0.5-1.5 mm²		 view
DSQIA4 For insulated flag terminals
AWG 22-18 / 16-14
0.5-1.0 / 1.5-2.5 mm²		 view
DSQIA5 For heat shrink & closed end terminals
AWG 22-16 / 16-14 / 12-10
0.5-1.5 / 1.5-2.5 / 4.0-6.0 mm²		 view
DSQIB  For non-insulated terminals
AWG 20-16 / 16-14 / 12-10 / 8
0.5-1.5 / 1.5-2.5 / 4.0-6.0 / 10.0 mm²		 view
DSQIC  For open-barrel terminals
AWG 20-18 / 16-14 / 12-10
0.5-1.0 / 1.5-2.5 / 4.0-6.0 mm²		 view
DSQICQ  For open-barrel terminals
AWG 20-18 / 16-14 / 12-10
0.5-1.0 / 1.5-2.5 / 4.0-6.0 mm²
MIM procedure		 view
DSQIC1  For open-barrel terminals
AWG 26-24 / 24-22 / 22-18
0.1-0.25 / 0.25-0.5 / 0.5-1.0 mm²		 view
DSQIC3 For open-barrel flag terminals
AWG 14-20 / 16-20
2.5-0.5 / 1.5-0.5 mm²		 view
DSQID  For insulated cord-end terminals (small wire size)
AWG 20 / 18 / 17 / 16 / 14 / 12
0.5 / 0.75 / 1.0 / 1.5 / 2.5 / 4.0 mm²		 view
DSQIE  For RG type coaxial cable connectors
.255 / .213 / .100 / .068 / .324 inch
6,48 / 5,41 / 2,54 / 1,72 / 8,23 mm
RG 58, 59, 62, 6 		 view
DSQIE1  For RG type coaxial cable connectors
.255 / .187 / .068 / .213 inch
6,48 / 4,75 /1,72 / 5,41 mm
RG 58, 59, 62, 174 		 view
DSQIE2  For RG type coaxial cable connectors
.256 / .319 / .068 / .213 inch
6,50 / 8,10 / 1,72 / 5,41 mm
RG 58, 59, 62, 6 		 view
DSQIE3  For RG type coaxial cable connectors
.043 / .068 / .100 / .137 / .213 / .255 inch
1,09 / 1,72 / 2,54 / 3,48 / 5,41 / 6,48 mm
RG 58, 59, 62, 174 Fiber Optic 		 view
DSQIE4  For RG type coaxial cable connectors
.100 / .128 / .429 inch
2,54 / 3,25 / 10,9 mm
RG 8, 11, 174, 179, 213 		 view
DSQIE5  For RG type coaxial cable connectors
.042 / .068 / .078 / .128 / .151 / .178 inch
1,07 / 1,72 / 1,98 / 3,25 / 3,84 / 4,52 mm
RG 174, 179 Belden 8218 Fiber Optic 		 view
DSQIE6  For RG type coaxial cable connectors
.100 / .213 / .319 / .360 inch
2,54 / 5,41 / 8,10 / 9,14 mm
RG 58, 59, 6 		 view
DSQIF  For insulated cord-end terminals (medium wire size)
AWG 10 / 8-6
6.0 / 10.0 / 16.0 mm²		 view
DSQIF1 For insulated cord-end terminals (large wire size)
AWG 4 / 2
25.0 / 35.0 mm²		 view
DSQIH  For open-barrel terminals & D-SUB V3.5
AWG 14 / 22 / 8-6
2.5 / 0.5 / 8.0-10.0 mm²		 view
DSQIH1  For spark plug connectors
AWG 17
1.0 mm²		 view
DSQIH2 For open barrel terminals (for AMP superseal)
AWG 22-20 / 16
DIN 0.35-0.5 / 1.5 mm²		 view
DSQIH3 For open barrel terminals (for AMP superseal)
AWG 18 / 17
DIN 0.75-1.0 mm²		 view
DSQIH6 For open barrel terminals (for weatherpack terminals)
AWG 22 / 20-18
0.35 / 0.5-0.8 mm²		 view
DSQIH7 For open barrel terminals (for weatherpack terminals)
AWG 16-14 / 12
1.0-2.0 / 3.0 mm²		 view
DSQIIQ1 (IQ1)  For MC3 solar connectors
AWG 14 / 12 / 10
2.5 / 4.0 / 6.0 mm²
MIM Procedure		 view
DSQII2  For MC4 solar connectors
AWG 14 / 12 / 10
2.5 / 4.0 / 6.0 mm²		 view
DSQIIQ2 (IQ2) For MC4 solar connectors
AWG 14 / 12 / 10
2.5 / 4.0 / 6.0 mm²
MIM Procedure		 view
DSQIIQ3 (IQ3)  For Tyco solar connectors
AWG 15-10
1.5 / 2.5 / 4.0 / 6.0 mm²
MIM Procedure		 view
DSQIK1 For open-barrel Deutsch terminals (DT P series)
AWG 14 / 12
2.0 / 4.0 mm²		 view
DSQIK2 For open-barrel Deutsch terminals (DT P series)
AWG 12 / 10
5.0 / 6.0 mm²		 view
DSQIK3 For open-barrel Deutsch terminals (DT series)
AWG 18 / 16 / 14
1.0 / 1.5 / 2.5 mm²		 view
DSQIK4 For open-barrel Deutsch terminals (DT series)
AWG 20 / 18 / 16
0.5 / 0.8 / 1.0 mm²		 view
DSQIK5 For open-barrel Deutsch terminals (DT M series)
AWG 20 / 18 / 16
0.5 / 0.8 / 1.0 mm²		 view
DSQIK6 For open-barrel Deutsch terminals (DT series)
AWG 16 / 14 / 12
1.0 / 2.0 / 2.5 mm²		 view
DSQIKQ8 For solid Deutsch terminals (4 indent crimp)
AWG 20 / 16 / 12
0.5 / 1.0 / 2.5-4.0 mm²
MIM Procedure		 view
DSQIL For female JPT and VAG terminals with or without seal

Without seal:
AWG 24-20
0.2-0.5 mm²

With seal:
AWG 24-20 / 20-18 / 16-14
0.2-2.5 mm² 		view
DSQIL1 For male JPT, VAG and MCP terminals with or without seal
AWG 20-18 / 16-14
0.5-1.0 / 1.5-2.5 mm²		 view
DSQIL2 For female JT (0.12-2.5 mm²) and ST (0.2-2.5 mm²) terminals
AWG 20-18 / 16 / 18-16 / 14
0.5-1.0 / 1.5 /1.0-1.5 / 2.5 mm²
Suitable for insulation-reduced stranded wires		 view
DSQIL10 For SPT and MCP terminals
AWG 24-20 / 20-17 / 15-13 / 11
0.2-0.5 / 0.5-1.0 / 1.5-2.5 / 4.0 mm²
Suitable for insulation-reduced stranded wires		 view
DSQIL11 For female SPT terminals with single wire sealing system
AWG 20-17 / 17-13 / 13-11
0.5-1.0 / 1.5-2.5 / 3.0-4.0 mm²		 view
ASSAETOOL02  Kit
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIA / DSQIB / DSQIC / DSQID / DSQIF / DSQIH		 ASSAETOOL02
ASSAETOOL02-1 Kit without tool
+ DSQIA / DSQIB / DSQIC / DSQID / DSQIF		 ASSAETOOL02-1
ASSAETOOL03 Kit for Deutsch open-barrel terminals
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIK1 / DSQIK2 / DSQIK3 / DSQIK4 / DSQIK5 / DSQIK6		 ASSAETOOL-03
ASSAETOOL04 Kit for solid Deutsch terminals
+ 8,7" carbon steel crimping tool
+ die set for 0.5/1.5/4.0 mm² terminals
+ wedge removal/small screwdriver combi tool
+ 3 Terminal release tools for size 20, 16 and 12 terminals		 ASSAETOOL04
ASSAETOOL10 Kit
+ HJ56I (10" carbon steel ratchet tool)
+ DSQIA / DSQIB / DSQIC / DSQIC1 / DSQIH / DSQIH1		 view
ASSAETOOL33 Kit
+ HJ43I (8,7" aluminum ratchet tool)
+ DSQIC / DSQIC1 / DSQIH		 ASSAETOOL33
ASSAETOOL55 Kit
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIA1 / DSQIA2 / DSQIA3 / DSQIA4 / DSQIA5		 ASSAETOOL55
ASSAETOOL60 Kit
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIA / DSQIA3
Is is possible to choose another combination of die sets		 ASSAETOOL60
ASSAETOOL61 Kit
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIC / DSQIC1
It is possible to choose another combination of die sets		 ASSAETOOL61
ASSAETOOL62 Kit
+ MHQIBE (carbon steel 8,7" ratchet tool)
+ DSQIK3 / DSQIK4
It is possible to choose another combination of die sets		 ASSAETOOL62
HI310052BC Professional black case
+ HJ56I (10" carbon steel ratchet tool)
+ DSQIA
+ insulation tape and 50 cable ties (2,5x100 mm)
19 empty compartments		 HI310052BC
HJ410006BC-H2H3 Professional black case
+ HJ43I (8,7" aluminum ratchet tool)
+ DSQIH2 / DSQIH3
22 empty compartments		 HJ410006BC-H2H3
9086BB Empty case for a 8.7" tool
+ 2 or 3 die sets		 9086-BB
ASSAETOOL CASE Empty case for a 8,7" tool
+ 5 die sets		 view
